Communication Module DVPSCM12/52-SL
DVP-PLC Operation Manual
11
CR#32: Triggering the data exchange through COM2 to read bits or words
[Description]
High byte: COM2 Bit; Low byte: COM2 Word
0: Not triggered; 1: Triggered once; 2: Always triggered
Please refer to the table in the description of CR#31 for hexadecimal values.
CR#33: Triggering the data exchange through COM1 to write bits or words
[Description]
High byte: COM1 Bit; Low byte: COM1 Word
0: Not triggered; 1: Triggered once; 2: Always triggered
Please refer to the table in the description of CR#31 for hexadecimal values.
CR#34: Triggering the data exchange through COM2 to write bits or words
[Description]
High byte: COM2 Bit; Low byte: COM2 Word
0: Not triggered; 1: Triggered once; 2: Always triggered
Please refer to the table in the description of CR#31 for hexadecimal values.
CR#35~36: Selecting the “reading bits through COM1” checkbox
[Description]
Select the “reading bits through COM1” checkbox. The SCM module can read at most 32 groups of data
(No.1~No.32).
CR# CR35
Bit b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
No. 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
CR#35: No.16~No.1; CR#36: No.32~No.17
0: Enabling the function; 1: Disabling the function
CR#37~38: Selecting the “reading words through COM1” checkbox
[Description]
Select the “reading words through COM1” checkbox. The SCM module can read at most 32 groups of data
(No.1~No.32).
CR#37: No.16~No.1; CR#38: No.32~No.17
0: Enabling the function; 1: Disabling the function
