Figure 9-2 M30A Thermal Derating Curve (cosφ=0.95)
0.5
0.55
0.6
0.65
0.7
0.75
0.8
0.85
0.9
0.95
1
1.05
1.1
1.15
25℃ 30℃ 35℃ 40℃ 45℃ 50℃ 55℃ 60℃
S(520V)
S(600V)
S(800V)
P(520V)
P(600V)
P(800V)
P/Pn*
Pn*=30kW
Ambient Temperature
Temperature Derating of RPI M30A
cos(Φ)=0.95
