Delta RT Series - Page 26

Amplon RT Series
26
Unscrew the screws and pull out the UPS’s front bezel .
(Figure 6-4: Remove the screws.)
Pull out the control panel , rotate the panel and the Delta logo nameplate 90° clockwise
 and re-insert the control panel  (see
Figure 6-5
). Re-attach the front bezel to the UPS and
tighten the screws  (see
Figure 6-6)
.

(Figure 6-5: Rotate the Control Panel and the Delta Logo Nameplate)

(Figure 6-6: Reattach the front bezel to the UPS.)
