Firmware Version Look-up
z
Check the UPS rmware version from the LCD.
V00: UPS Firmware Version
CV00: Compatible Version Code.
z
When two units are in parallel, each detects whether the compatible version code of the other
is the same. If not, the UPS won’t turn on and the alarm message below appears.
z
If the message above appears, please contact your local dealer to upgrade the rmware.
z
LCD Display Messages:
LCD Message Meaning
ONLINE MODE Indicates the UPS is in online mode.
STANDBY MODE Indicates the UPS is in standby mode
ECO MODE Indicates the UPS is in ECO mode.
BATTERY MODE Indicates the UPS is in battery mode.
BYPASS MODE Indicates the UPS is in bypass mode.
CONVERTER MODE Indicates the UPS is in converter mode.
STANDALONE Indicates that there is only one UPS.
PARALLEL: MASTER
Indicates that, in parallel mode, this is the MASTER
UPS.
PARALLEL: SLAVE
Indicates that, in parallel mode, this is the SLAVE UPS.
INPUT VOLTAGE Indicates the input voltage.
BYPASS VOLTAGE Indicates the bypass voltage.
OUTPUT VOLTAGE Indicates the output voltage.
BATTERY CAPACITY Indicates the battery capacity.
REMAINING TIME Indicates the remaining battery time.
ONLINE XKVA Indicates the UPS power rating, rmware version and
compatible version code.
To Next Page
