28
Amplon RT Series
NChapter 9: Specifications
*1: The power factor can be modi ed into 0.8 to let the UPS rating change from 5kVA/ 4.5kW, 6kVA/ 5.4kW and 10kVA/ 9kW into 5.5kVA/ 4.4kW,
7kVA/ 5.6kW and 11kVA/ 8.8kW respectively.
*2: At room temperature, at a distance of 1 meter in front of the UPS and when the load is 70% of the rating load.
NOTE:
Ú Refer to the rating label for the safety rating.
Ú All speci cations are subject to change without prior notice.
Ú For power factor modi cation, please contact your local dealer or customer service.
Model RT5k RT6k RT10k
1. Power (Va/W)
5000VA/4500W *
1
6000VA/5400W *
1
10000VA/9000W *
1
2. Waveform
Pure Sine Wave
3. Input
3.1 Input Voltage (Single)
100 ~ 155Vac (50% ~ 100% load) 100 ~ 180Vac (50% ~ 100% load)
156 ~ 280Vac (100% load) /
281 ~ 300Vac (90% load)
180 ~ 280Vac (100% load) /
281 ~ 300Vac (90% load)
3.2 Input Current 29.7A 35.9A 56.1A
- Inrush Current < 200A
- Power Factor (Full Load) > 0.99
3.3 Ef ciency (Full Resistance Load)
- On Line Mode (Full Load) 92%
- ECO Mode (Full Load) 96%
3.4 Input Frequency 40 ~ 70 Hz
4. Output
4.1 RMS Output Voltage (Single) 200Vac/208Vac/220Vac/230Vac(default)/240Vac
4.2 Overload Capability 106% ~ 110%: 10 minutes; 111% ~ 125%: 5 minutes; 126% ~ 150%: 30 seconds
4.3 The Overload Release (Rating Load) 95%
4.4 Output Frequency (Battery Mode) 50/60 Hz ± 0.05 Hz
4.5 Crest Factor (CF) 3:1
5. Battery & Charger
5.1 Type Sealed Lead-Acid Battery
5.2 Number of Battery 12V x 16 pcs 12V x 20 pcs
5.3 Charge Current 4A (maximum) 4A (maximum)
6. Operation- Audible Noise
54 dBA *
2
7. Appearance
7.1 Dimensions- Width x Depth x Height
(I/P & O/P Box Included)
440.0 x 670.5 x 88.5 mm 440.0 x 623.0 x 130.6 mm
7.2 Net Weight 15.5 Kg 21.3 Kg
8. Environment
8.1 Operating Temperature 0 ~ 40°C
8.2 Storage Temperature -15 ~ 50°C
8.3 Relative Humidity 0 ~ 95% (non-condensing)
To Next Page
