Chapter 11 Summary of Parameter SettingsCFP2000 Series
11-1
Chapter 11 Summary of Parameter Settings
This chapter provides summary of parameter settings for user to gather the parameter setting ranges,
factory settings and set parameters. The parameters can be set, changed and reset by the digital keypad.
NOTE
1) : the parameter can be set during operation
2) For more detail on parameters, please refer to Ch12 Description of Parameter Settings.
00 Drive Parameters
Pr.
Explanation
Settings
Factory
Setting
00-00
Identity Code of the AC Motor Drive
5:460V,1HP(0.75kW)
7:460V,2HP(1.5kW)
9:460V,3HP(2.2kW)
11:460V,5HP(3.7kW)
13:460V,7.5HP(5.5kW)
15:460V,10HP(7.5kW)
17:460V,15HP(11kW)
19:460V,20HP(15kW)
21:460V,25HP(18.5kW)
23:460V,30HP(22kW)
25:460V,40HP(30kW)
27:460V,50HP(37kW)
29:460V,60HP(45kW)
31:460V,75HP(55kW)
33:460V,100HP(75kW)
35:460V,125HP(90kW)
93:460V,5.5HP(4.0kW)
Read
only
00-01
Display AC Motor Drive Rated
Current
Display by models
Read
only
00-02
Parameter Reset
0: No function
1: Parameter write protect
5: Reset KWH display to 0
6: Reset PLC (including CANopen Master Index)
7: Reset CANopen Index (Slave)
9: All parameters are reset to factory settings(base
frequency is 50Hz)
10: All parameters are reset to factory settings (base
frequency is 60Hz
0
00-03
Start-up Display Selection
0: F (frequency command)
1: H (output frequency)
2: U (multi-function display, see Pr.00-04)
3: A (output current)
0
00-04
Content of Multi-function Display
0: Display output current (A) (Unit: Amps)
1: Display counter value (c) (Unit: CNT)
2: Display actual output frequency (H.) (Unit: Hz)
3: Display DC-BUS voltage (v) (Unit: Vdc)
4: Display output voltage (E) (Unit: Vac)
5: Display output power angle (n) (Unit: deg)
6: Display output power in kW (P) (Unit: kW)
7: Display actual motor speed rpm (r) (Unit: rpm)
8: Reserved
9: Reserved
10: Display PID feedback (b) (Unit: %)
11: Display AVI in % (1.) (Unit: %)
12: Display ACI in % (2.) (Unit: %)
3
