Chapter 11 Summary of Parameter SettingsCFP2000 Series
11-2
Pr.
Explanation
Settings
Factory
Setting
13: Display AUI in % (3.) (Unit: %)
14: Display the temperature of IGBT in ℃ (i.) (Unit:
℃)
15: Display the temperature of capacitance in ℃
(c.) (Unit: ℃)
16: The status of digital input (ON/OFF) (i)
17: The status of digital output (ON/OFF) (o)
18: Multi-step speed (S)
19: The corresponding CPU pin status of digital
input (d)
20: The corresponding CPU pin status of digital
output (0.)
21~24: Reserved
25: Overload count (0.00~100.00%) (h.) (Unit: %)
26: Ground Fault GFF(G.) (Unit: %)
27: DC Bus voltage ripple (Unit: Vdc) (r.)
28: Display PLC data D1043 (C)
29: Reserved
30: Display output of user defined (U)
31: Display Pr.00-05 user Gain(K)
32: Reserved
33: Reserved
34: Operation speed of fan (F.) (Unit: %)
35: Reserved
36: Present operating carrier frequency of drive (Hz)
(J.)
37: Reserved
38: Display drive status (6.)
39: Reserved
40: Reserved
41: KWH display (J) (Unit: kWH)
42: PID Reference (L) (Unit: %)
43: PID offset (o.) (Unit: %)
44: PID Output Fcmd(Hz) (b.) (Unit: Hz)
45: Hardware ID (0)

00-05
Coefficient Gain in Actual Output
Frequency
0~160.00
1.00
00-06
Software Version
Read only
#.#

00-07
Parameter Protection Password
Input
0~65535
0~4: the times of password attempts
0

00-08
Parameter Protection Password
Setting
0 ~ 65535
0: No password protection / password is entered
correctly (Pr00-07)
1: Parameter is locked
0
00-09
Reserved
00-10
Reserved
00-11
Control of Speed Mode
0: VF (IM V/f control)
2: SVC(IM/PM Sensorless vector control)
0
00-12
~
00-15
Reserved

00-16
Load Selection
0: Light load
1: Normal load
0
00-17
Carrier Frequency
1-25HP
2~15KHz
30-100HP
2~10KHz
125HP
2~9KHz
4
4
4
00-18
Reserved
00-19
PLC Command Mask
Bit 0: Control command by PLC force control
Bit 1: Frequency command by PLC force control
0
