Chapter 11 Summary of Parameter SettingsCFP2000 Series
11-6
01 Basic Parameters
Pr.
Explanation
Settings
Factory
Setting

01-00
Max. Operation Frequency
0.75~75kW (1~100HP): 50.00~599.00Hz
90kW (125HP): 0.00~400.00Hz
60.00/
50.00
01-01
Output Frequency of Motor 1
0.00~599.00Hz
60.00/
50.00
01-02
Output Voltage of Motor 1
0.0V~510.0V
400.0
01-03
Mid-point Frequency 1 of Motor 1
0.00~599.00Hz
3.00

01-04
Mid-point Voltage 1 of Motor 1
0.0V~480.0V
22.0
01-05
Mid-point Frequency 2 of Motor 1
0.00~599.00Hz
1.50

01-06
Mid-point Voltage 2 of Motor 1
0.0V~480.0V
10.0
01-07
Min. Output Frequency of Motor 1
0.00~599.00Hz
0.50

01-08
Min. Output Voltage of Motor 1
0.0V~480.0V
2.0
01-09
Start-Up Frequency
0.00~599.00Hz
0.50

01-10
Output Frequency Upper Limit
0.00~599.00Hz
599.00

01-11
Output Frequency Lower Limit
0.00~599.00Hz
0

01-12
Accel. Time 1
Pr.01-45=0: 0.00~600.00 second
Pr.01-45=1: 0.00~6000.0 second
10.00
10.0

01-13
Decel Time 1
Pr.01-45=0: 0.00~600.00 second
Pr.01-45=1: 0.00~6000.0 second
10.00
10.0

01-14
Accel Time 2
Pr.01-45=0: 0.00~600.00 second
Pr.01-45=1: 0.00~6000.0 second
10.00
10.0

01-15
Decel Time 2
Pr.01-45=0: 0.00~600.00 second
Pr.01-45=1: 0.00~6000.0 second
10.00
10.0

01-16
Accel Time 3
Pr.01-45=0: 0.00~600.00 second
Pr.01-45=1: 0.00~6000.0 second
10.00
10.0

01-17
Decel Time 3
Pr.01-45=0: 0.00~600.00 second
Pr.01-45=1: 0.00~6000.0 second
10.00
10.0

01-18
Accel Time 4
Pr.01-45=0: 0.00~600.00 second
Pr.01-45=1: 0.00~6000.0 second
10.00
10.0

01-19
Decel Time 4
Pr.01-45=0: 0.00~600.00 second
Pr.01-45=1: 0.00~6000.0 second
10.00
10.0

01-20
JOG Acceleration Time
Pr.01-45=0: 0.00~600.00 second
Pr.01-45=1: 0.00~6000.0 second
10.00
10.0

01-21
JOG Deceleration Time
Pr.01-45=0: 0.00~600.00 second
Pr.01-45=1: 0.00~6000.0 second
10.00
10.0

01-22
JOG Frequency
0.00~599.00Hz
6.00

01-23
1st/4th Accel/decel Frequency
0.00~599.00Hz
0.00

01-24
S-curve Acceleration Begin Time 1
Pr.01-45=0: 0.00~25.00 second
Pr.01-45=1: 0.0~250.0 second
0.20
0.2

01-25
S-curve Acceleration Arrival Time 2
Pr.01-45=0: 0.00~25.00 second
Pr.01-45=1: 0.0~250.0 second
0.20
0.2

01-26
S-curve Deceleration Begin Time 1
Pr.01-45=0: 0.00~25.00 second
Pr.01-45=1: 0.0~250.0 second
0.20
0.2
