Chapter 11 Summary of Parameter SettingsCFP2000 Series
11-7
Pr.
Explanation
Settings
Factory
Setting

01-27
S-curve Deceleration Arrival Time 2
Pr.01-45=0: 0.00~25.00 second
Pr.01-45=1: 0.0~250.0 second
0.20
0.2
01-28
Skip Frequency 1 (upper limit)
0.00~599.00Hz
0.00
01-29
Skip Frequency 1 (lower limit)
0.00~599.00Hz
0.00
01-30
Skip Frequency 2 (upper limit)
0.00~599.00Hz
0.00
01-31
Skip Frequency 2 (lower limit)
0.00~599.00Hz
0.00
01-32
Skip Frequency 3 (upper limit)
0.00~599.00Hz
0.00
01-33
Skip Frequency 3 (lower limit)
0.00~599.00Hz
0.00
01-34
Zero-speed Mode
0: Output waiting
1: Zero-speed operation
2: Fmin (Refer to Pr.01-07, 01-41)
0
01-35
Output Frequency of Motor 2
0.00~599.00Hz
60.00/
50.00
01-36
Output Voltage of Motor 2
0.0V~510.0V
400.0
01-37
Mid-point Frequency 1 of Motor 2
0.00~599.00Hz
3.00

01-38
Mid-point Voltage 1 of Motor 2
0.0V~480.0V
22.0
01-39
Mid-point Frequency 2 of Motor 2
0.00~599.00Hz
1.50

01-40
Mid-point Voltage 2 of Motor 2
0.0V~480.0V
10.0
01-41
Min. Output Frequency of Motor 2
0.00~599.00Hz
0.50

01-42
Min. Output Voltage of Motor 2
0.0V~480.0V
2.0
01-43
V/f Curve Selection
0: V/f curve determined by Pr.01-00~01-08
1: 1.5
th
V/F curve
2: 2
nd
V/F curve
3: 60Hz (voltage saturation in 50Hz)
4: 72Hz (voltage saturation in 60Hz)
5: 3
rd
decreasing (50Hz)
6: 2
nd
decreasing (50Hz)
7: 3
rd
decreasing (60Hz)
8: 2
nd
decreasing (60Hz)
9: Mid. Starting torque (50Hz)
10: High starting torque (50Hz)
11: Mid. Starting torque (60Hz)
12: High starting torque (60Hz)
13: 90Hz (voltage saturation in 60Hz)
14: 120Hz (voltage saturation in 60Hz)
15: 180Hz (voltage saturation in 60Hz)
0

01-44
Optimal Acceleration/Deceleration
Setting
0: Linear accel. /decel.
1: Auto accel.; linear decel.
2: Linear accel.; auto decel.
3: Auto accel./decel.
4: Linear, stall prevention by auto accel./decel. (limit
by Pr.01-12~01-21)
0
01-45
Time Unit for Accel. /Decel. and S
Curve
0: Unit: 0.01 sec
1: Unit: 0.1 sec
0

01-46
CANopen Quick Stop Time
Pr. 01-45=0: 0.00~600.00 sec
Pr. 01-45=1: 0.0~6000.0 sec
1.00/
1.0
01-47
Reserved
01-48
Reserved
01-49
Deceleration Method
0: Normal decel.
1: Over fluxing decel.
2: Traction energy control
0
