Chapter 11 Summary of Parameter SettingsCFP2000 Series
11-8
02 Digital Input/Output Parameters
Pr.
Explanation
Settings
Factory
Setting
02-00
2-wire/3-wire Operation Control
0: 2-wire mode 1, power on for operation control
1: 2-wire mode 2, power on for operation control
2: 3-wire, power on for operation control
0
02-01
Multi-function Input Command 1
(MI1)
0: No function
1
02-02
Multi-function Input Command 2
(MI2)
1: Multi-step speed command 1/multi-step position
command 1
2
02-03
Multi-function Input Command 3
(MI3)
2: Multi-step speed command 2/multi-step position
command 2
3
02-04
Multi-function Input Command 4
(MI4)
3: Multi-step speed command 3/multi-step position
command 3
4
02-05
Multi-function Input Command 5
(MI5)
4: Multi-step speed command 4/multi-step position
command 4
0
02-06
Multi-function Input Command 6
(MI6)
5: Reset
0
02-07
Multi-function Input Command 7
(MI7)
6: JOG command（By KPC-CC02 or external control）
0
02-08
Multi-function Input Command 8
(MI8)
7: Acceleration/deceleration speed inhibit
0
02-26
Input terminal of I/O
extension card (MI10)
8: The 1
st
, 2
nd
acceleration/deceleration time selection
0
02-27
Input terminal of I/O extension
card (MI11)
9: The 3
rd
, 4
th
acceleration/deceleration time selection
0
02-28
Input terminal of I/O extension
card (MI12)
10: EF Input (Pr.07-20)
0
02-29
Input terminal of I/O extension
card (MI13)
11: B.B input from external (Base Block)
0
02-30
Input terminal of I/O extension
card (MI14)
12: Output stop
0
02-31
Input terminal of I/O extension
card (MI15)
13: Cancel the setting of optimal accel. /decel. time
0
14: Switch between motor 1 and motor 2
15: Operation speed command from AVI1
16: Operation speed command from ACI
17: Operation speed command from AVI2
18: Emergency stop (Pr.07-20)
19: Digital up command
20: Digital down command
21: PID function disabled
22: Clear counter
23: Input the counter value (MI6)
24: FWD JOG command
25: REV JOG command
26: Reserved
27: Reserved
28: Emergency stop (EF1)
29: Signal confirmation for Y-connection
30: Signal confirmation for -connection
31~37: Reserved
38: Disable EEPROM write function
39: Reserved
40: Force coast to stop
41: HAND switch
42: AUTO switch
43~48: Reserved
49: Drive enable
50: Slave dEb action to execute
51: Selection for PLC mode bit0
