Chapter 11 Summary of Parameter SettingsCFP2000 Series
52: Selection for PLC mode bit1
53: Trigger CANopen quick stop
54: UVW Output Electromagnetic valve Switch
56: Local/Remote Selection
58: Enable fire mode (with RUN Command)
59: Enable fire mode (without RUN Command)
0: up/down by the accel. /decel. time
1: up/down constant speed (Pr.02-10)
Constant speed. The Accel.
/Decel. Speed of the UP/DOWN
Key
Digital Input Response Time
Digital Input Mode Selection
0000h~FFFFh (0: N.O.; 1: N.C.)
Multi-function Output 1 RY1
Multi-function Output 2 RY2
Multi-function Output 3 RY3
2: Operation speed attained
Output terminal of the I/O
extension card (MO10 or RA10)
3: Desired frequency attained 1 (Pr.02-22)
Output Terminal of I/O Extension
Card (MO11 or RA11)
4: Desired frequency attained 2 (Pr.02-24)
Output Terminal of I/O Extension
Card (MO12 or RA12)
5: Zero speed (Frequency command)
Output Terminal of I/O Extension
Card (MO13 or RA13)
6: Zero speed, include STOP(Frequency command)
Output Terminal of I/O Extension
Card (MO14 or RA14)
7: Over torque 1(Pr.06-06~06-08)
Output Terminal of I/O Extension
Card (MO15 or RA15)
8: Over torque 2(Pr.06-09~06-11)
Output Terminal of I/O Extension
Card (MO16)
Output Terminal of I/O Extension
Card (MO17)
10: Low voltage warning(LV)(Pr.06-00)
Output Terminal of I/O Extension
Card (MO18)
11: Malfunction indication
Output Terminal of I/O Extension
Card (MO19)
12: Mechanical brake release(Pr.02-32)
Output Terminal of I/O Extension
Card (MO20)
13: Overheat warning (Pr.06-15, OH1, OH2)
14: Software brake signal indication(Pr.07-00)
17: Terminal count value attained, does not return to 0
(Pr.02-20)
