Chapter 11 Summary of Parameter SettingsCFP2000 Series
11-14
Pr.
Explanation
Settings
Factory
Setting
03-47
~
03-49
Reserved

03-50
Analog Input Curve Selection
0: Regular Curve
1: 3 point curve of AVI1
2: 3 point curve of ACI
3: 3 point curve of AVI1 & ACI
4: 3 point curve of AVI2
5: 3 point curve of AVI1 & AVI2
6: 3 point curve of ACI & AVI2
7: 3 point curve of AVI1 & ACI & AVI2
7

03-51
AVI1 Low Point
Pr.03-28=0, 0.00~10.00V
Pr.03-28≠0, 0.00~20.00mA
0.00

03-52
AVI1 Proportional Low Point
-100.00~100.00%
0.00

03-53
AVI1 Mid Point
Pr.03-28=0, 0.00~10.00V
Pr.03-28≠0, 0.00~20.00mA
5.00

03-54
AVI1 Proportional Mid Point
-100.00~100.00%
50.00

03-55
AVI1 High Point
Pr.03-28=0, 0.00~10.00V
Pr.03-28≠0, 0.00~20.00mA
10.00

03-56
AVI1 Proportional High Point
-100.00~100.00%
100.00

03-57
ACI Low Point
Pr.03-29=1, 0.00~10.00V
Pr.03-29≠1, 0.00~20.00mA
4.00

03-58
ACI Proportional Low Point
-100.00~100.00%
0.00

03-59
ACI Mid Point
Pr.03-29=1, 0.00~10.00V
Pr.03-29≠1, 0.00~20.00mA
12.00

03-60
ACI Proportional Mid Point
-100.00~100.00%
50.00

03-61
ACI High Point
Pr.03-29=1, 0.00~10.00V
Pr.03-29≠1, 0.00~20.00mA
20.00

03-62
ACI Proportional High Point
-100.00~100.00%
100.00

03-63
Positive AVI2 Voltage Low Point
0.00~10.00V
0.00

03-64
Positive AVI2 Voltage
Proportional Low Point
-100.00%~100.00%
0.00

03-65
Positive AVI2 Voltage Mid Point
0.00~10.00V
5.00

03-66
Positive AVI2 Voltage
Proportional Mid Point
-100.00%~100.00%
50.00

03-67
Positive AVI2 Voltage High Point
0.00~10.00V
10.00

03-68
Positive AVI2 Voltage
Proportional High Point
-100.00%~100.00%
100.00
