Chapter 11 Summary of Parameter SettingsCFP2000 Series
11-13
Pr.
Explanation
Settings
Factory
Setting

03-20
Multi-function Output 1 (AFM1)
0: Output frequency (Hz)
0

03-23
Multi-function Output 2 (AFM2)
1: Frequency command (Hz)
0
2: Motor speed (Hz)
3: Output current (rms)
4: Output voltage
5: DC Bus voltage
6: Power factor
7: Power
8: Reserved
9: AVI1
10: ACI
11: AVI2
12~19: Reserved
20: CANopen analog output
21: RS485 analog output
22: Communication card analog output
23: Constant voltage/current output

03-21
Gain of Analog Output 1 (AFM1)
0~500.0%
100.0

03-22
Analog Output 1 when in REV
Direction (AFM1)
0: Absolute output voltage
1: Reverse output 0V; Positive output 0-10V
2: Reverse output 5-0V; Positive output 5-10V
0

03-24
Gain of Analog Output 2 (AFM2)
0~500.0%
100.0

03-25
Analog Output 2 when in REV
Direction (AFM2)
0: Absolute output voltage
1: Reverse output 0V; Positive output 0-10V
2: Reverse output 5-0V; Positive output 5-10V
0

03-26
Reserved

03-27
AFM2 Output Bias
-100.00~100.00%
0.00

03-28
AVI1 Selection
0: 0-10V
1: 0-20mA
2: 4-20mA
0

03-29
ACI Selection
0: 4-20mA
1: 0-10V
2: 0-20mA
0
03-30
Status of PLC Output Terminal
Monitor the status of PLC output terminals
0000

03-31
AFM2 Output Selection
0: 0-20mA Output
1: 4-20mA Output
0

03-34
AFM1 Output Selection
0: 0-20mA Output
1: 4-20mA Output
0

03-32
AFM1 DC output setting level
0.00~100.00%
0.00

03-33
AFM2 DC Output Setting Level
0.00~100.00%
0.00

03-35
AFM1 filter output time
0.00 ~ 20.00 Seconds
0.01

03-36
AFM2 filter output time
0.00 ~ 20.00 Seconds
0.01
03-37
~
03-43
Reserved

03-44
MO by source of AI level
0: AVI1
1: ACI
2: AVI2
0

03-45
AI upper level
-100.00%~100.00%
50.00%

03-46
AI lower level
-100.00%~100.00%
10.00%
