Chapter 11 Summary of Parameter SettingsCFP2000 Series
11-12
03 Analog Input/Output Parameters
Pr.
Explanation
Settings
Factory
Setting

03-00
Analog Input Selection (AVI1)
0: No function
1

03-01
Analog Input Selection (ACI)
1: Frequency command (speed limit under torque
control mode)
0

03-02
Analog Input Selection (AVI2)
2~3: Reserved
0
4: PID target value
5: PID feedback signal
6: PTC thermistor input value
7~10: Reserved
11: PT100 thermistor input value
12: Reserved
13: PID Bias Value
14~17: Reserved

03-03
Analog Input Bias (AVI1)
-100.0~100.0%
0

03-04
Analog Input Bias (ACI)
-100.0~100.0%
0

03-05
Analog Input Bias (AVI2)
-100.0~100.0%
0
03-06
Reserved

03-07
Positive/negative Bias Mode
(AVI1)
0: No bias
1: Lower than or equal to bias
2: Greater than or equal to bias
3: The absolute value of the bias voltage while serving
as the center
4: Serve bias as the center
0

03-08
Positive/negative Bias Mode
(ACI)

03-09
Positive/negative Bias Mode
(AVI2)
03-10
Analog Frequency Command
for Reverse Run
0: Negative frequency is not valid. Forward and
reverse run is controlled by digital keypad or
external terminal.
1: Negative frequency is valid. Positive frequency =
forward run; negative frequency = reverse run.
Direction can not be switched by digital keypad or
external terminal control.
0

03-11
Analog Input Gain (AVI1)
-500.0~500.0%
100.0

03-12
Analog Input Gain (ACI)
-500.0~500.0%
100.0

03-13
Analog Positive Input Gain 1
(AVI2)
-500.0~500.0%
100.0

03-14
Analog Negative Input Gain 2
(AVI2)
-500.0~500.0%
100.0

03-15
Analog Input Filter Time (AVI1)
0.00~20.00 sec.
0.01

03-16
Analog Input Filter Time (ACI)
0.00~20.00 sec.
0.01

03-17
Analog Input Filter Time (AVI2)
0.00~20.00 sec.
0.01

03-18
Addition Function of the Analog
Input
0: Disable (AVI1, ACI, AVI2)
1: Enable
0

03-19
ACI Signal Loss
0: Disable
1: Continue operation at the last frequency
2: Decelerate to 0Hz
3: Stop immediately and display ACE
0
