Chapter 12 Description of Parameter Settings|CFP2000 Series
12.1-02-23
Parameter Description Setting Range Explanation
02-72 Output Current
Level of Preheating
0~100% (Rated Current of the Motor)
0% No output
02-73 Output Cycle of
Preheating
0~100% (0~10sec)
0% No output
100% Continuous output
02-01~08
02-26~31
Multi-Input Function
Commands
(MFI)
69 Preheating Command
Enable or Disable the
Preheating
02-13~15
02-36~46
Multi-Output
Function
Commands
(MFO)
69 Output Command of Preheating Indication of the
Preheating
Enable the Preheating: When Pr02-72 and Pr02-73 are NOT set to zero, the preheating is
enabled.
Preheating Function A: If Pr07-72 and Pr07-23 are set before the motor drive stops operation
(STOP), the preheating will be enabled right after the motor drive stops. However if Pr07-72 and
Pr07-73 are set after the motor drives stops operation, then preheating will not be enabled. Only
after the motor drive stops again or restarts, the preheating will be enabled.
Preheating Function B: When motor drive is in operation (RUN) or stops operating (STOP), set
Pr02-72 and Pr02-73 between 1% ~100% and set MFI= 69 and MFI = On. The preheating will
be enabled when the motor drive stops, No matter if the motor drive is in operation (RUN) or
stops operating (STOP).
Operation priority: When both the preheating function A and B are given, the function B has the
priority to operate.
02-72≠0
02-73≠0
Pre-Heat
Running
Drive
STOP
Drive STOP
&
MFI=ON(69)
