Chapter 12 Description of Parameter Settings|CFP2000 Series
12.1-03-20
Multi-function Output 1 (AFM1)
Factory Setting: 0
Multi-function Output 2 (AFM2)
Factory Setting: 0
Settings 0~23
Function Chart
Settings Functions Descriptions
0 Output frequency (Hz) Max. frequency Pr.01-00 is regarded as 100%.
1 Frequency command (Hz) Max. frequency Pr.01-00 is regarded as 100%.
2 Motor speed (Hz) 600Hz is regarded as 100%
3 Output current (rms) (2.5 X rated current) is regarded as 100%
4 Output voltage (2 X rated voltage) is regarded as 100%
5 DC Bus Voltage 450V (900V)=100%
6 Power factor -1.000~1.000=100%
7 Power Rated power is regarded as 100%
8 Reserved
9 AVI1
0~10V/ 0~20mA/ 4~20mA =0~100%
10 ACI
4~20mA/ 0~10V/ 0~20mA =0~100%
11 AVI2
0~10V/ 0~20mA/ 4~20mA =0~100%
12~19 Reserved
20 Output for CANopen control
For CANopen analog output
21 RS485 analog output
For communication output (CMC-MOD01, CMC-EIP01,
CMC-PN01, CMC-DN01)
22
Analog output for
communication card
For communication output (CMC-MOD01, CMC-EIP01,
CMC-PN01, CMC-DN01)
23 Constant voltage/current output
Pr.03-32 and Pr.03-33 controls voltage/current output
level
0~100% of Pr.03-32 corresponds to 0~10V of AFM1.
Gain of Analog Output 1 (AFM1)
Factory Setting: 100.0
Gain of Analog Output 2 (AFM2)
Factory Setting: 100.0
Settings 0~500.0%
It is used to adjust the analog voltage level (Pr.03-20) that terminal AFM outputs.
This parameter is set the corresponding voltage of the analog output 0.
Analog Output 1 when in REV Direction (AFM1)
Factory Setting: 0
Analog Output 2 when in REV Direction (AFM2)
Factory Setting: 0
