Chapter 12 Description of Parameter Settings|CFP2000 Series
12.1-05-6
Reserved
Reserved
Motor drive’s Accumulated Operating Watt per Hour (W-Hour)
Factory Setting: 0.0
Settings Read only
Motor drive’s Accumulated Operating Kilowatt per Hour (KW-Hour)
Factory Setting: 0.0
Settings Read only
Motor Drive’s Accumulated Operating Megawatt per Hour (MW-Hour)
Factory Setting: 0.0
Settings Read only
Pr.05-26~05-29 records the amount of power consumed by motors. The accumulation begins
when the drive is activated and record is saved when the drive stops or turns OFF. The amount
of consumed watts will continue to accumulate when the drive activate again. To clear the
accumulation, set Pr.00-02 to 5 then the accumulation record will return to 0.
For example, set Pr05-28=400Wh, Pr05-29=150kWh, Pr05-30=76MWh. The total accumulated
power is 76150.4kWh.
Accumulative Motor Operation Time (Min)
Factory Setting: 0
Settings 00~1439
Accumulative Motor Operation Time (day)
Factory Setting: 0
Settings 00~65535
Pr. 05-31 and Pr.05-32 are used to record the motor operation time. To clear the operation time,
set Pr.05-31 and Pr.05-32 to 00. Operation time shorter than 60 seconds will not be recorded.
Induction Motor (IM) and Permanent Magnet Motor Selection
Factory Setting: 0
Settings 0: Induction Motor
1: Permanent Magnet Motor (SPM)
2: Permanent Magnet Motor (IPM)
Full-load current of Permanent Magnet Motor
Factory Setting: 0.00
Settings 0.00~655.35 Amps
Set this parameter in accord to motor’s nameplate. Default setting is 90% motor drive rated
current.
For example: 7.5HP（5.5kW） rated current is 25A, then Pr05-34 default is 22.5A
Setting range will be 10~30A (25*10%=2.5A 25*120%=30A)
