Chapter 12 Description of Parameter Settings|CFP2000 Series
12.1-05-7

Rated Power of Permanent Magnet Motor
Factory Setting: 0.00
Settings 0.00~655.35 kW
 Set motor rated power in accord to motor nameplate. Default setting is motor drive rated power.

Rated speed of Permanent Magnet Motor
Factory Setting: 2000
Settings 0~65535 rpm
Pole number of Permanent Magnet Motor
Factory Setting: 10
Settings 0~65535
Inertia of Permanent Magnet Motor
Factory Setting: 0.0
Settings 0.0~6553.5 kg.cm
2
(0.0001kg.m
2
)
 Default value will follow the chart
Rated Power
(kW)
0.4 0.75 1.5 2.2 3.7 5.5 7.5 9.3 11
Rotor inertia
(kg.cm
2
)
1.2 3.0 6.6 15.8 25.7 49.6 82.0 121.6 177.0
Rated Power
(kW)
14.1 18.2 27 33 40 46 54
Above
54
Rotor inertia
(kg.cm
2
)
211.0 265.0 308.0 527.0 866.0 1082.0 1267.6 1515.0
Stator Resistance of PM Motor
Factory Setting: 0.000
Settings
0.000~65.535Ω
Permanent Magnet Motor Ld
Factory Setting: 0.00
Settings 0.00~655.35 mH
Permanent Magnet Motor Lq
Factory Setting: 0.00
Settings 0.00~655.35 mH

PG Offset angle of PM Motor
Factory Setting: 0.0
Settings 0.0~360.0°
 When Pr.05-00 is set to 4, the drive will detect offset angle and write into Pr.05-42.

Ke parameter of PM Motor
Unit: V/1000rpm
Factory Setting: 0
Settings 0~65535
