Chapter 12 Description of Parameter Settings|CFP2000 Series
12.1-06-22
6. Set Pr.06-57=1.42 and Pr.06-29=1 (warning and decelerate to stop). When RTD temperature
increases to 150℃ or higher, the drive will decelerate to stop and outputs an ‘OH3’ warning.
Software Detection GFF Current Level
Factory Setting: 60.0
Settings 0.0~6553.5 %
Software Detection GFF Filter Time
Factory Setting: 0.10
Settings 0.00~655.35 sec
When the motor drive detects the unbalanced three-phase out current is higher than the setting of
Pr.06-60, GFF protection will be activated. Then the motor drive will stop outputting.
When 3-phase current output unbalance value has exceeds Pr.06-60 setting, drive will trip up
GFF and stop output immediately.
Reserved
Fault Record 1 (day)
Fault Record 2 (day)
Fault Record 3 (day)
Fault Record 4 (day)
Factory Setting: Read only
Settings 0~65535 days
Fault Record 1 (min)
Fault Record 2 (min)
Fault Record 3 (min)
Fault Record 4 (min)
Factory Setting: Read only
Settings 0~1439 min
When there is any malfunctions in motor drive operation, Pr.06-17~22 will record 6 malfunctions
recently, and Pr.06-63~70 can record the operation time for 4 malfunctions in sequence. It can
help to check if there is any wrong with the drive according to the recorded internal time.
For example: The first error: ocA occurs in 1000 minutes after motor drive start operation. The
second error: ocd happens after another 1000 minutes. The 4
th
error: ocA happens after another
1000 minutes. Then, the 5
th
error is ocd, happening 1000 minutes following 4
th
error. Last, 6
th
error ocn happens 1000 minutes after 5
th
error.
Then Pr.06-17~Pr.06-22 and Pr.06-63~Pr.06-70 will be:
1
st
fault 2
nd
fault 3
rd
fault 4
th
fault 5
th
fault 6
th
fault
06-17 ocA ocd ocn ocA ocd ocn
06-18 0 ocA ocd ocn ocA ocd
06-19 0 0 ocA ocd ocn ocA
06-20 0 0 0 ocA ocd ocn
