Chapter 12 Description of Parameter Settings|CFP2000 Series
12.1-06-26
Code Error name
Normal
mode
Fire Mode
Enable bypass
function
21 Over Load (oL) (150% 1Min, Inverter) V Not-detectable Not-detectable
22 Motor 1 over load (EoL1) V Not-detectable Not-detectable
23 Motor 2 over load (EoL2) V Not-detectable Not-detectable
24 Over heat 3 (oH3) (PTC) V V(able to auto-reset) V
26 Over torque 1 (ot1) V Not-detectable Not-detectable
27 Over torque 2 (ot2) V Not-detectable Not-detectable
30 EEPROM write error (cF1) V Not-detectable Not-detectable
31 EEPROM read error (cF2) V V Not-detectable
33
U phase current sensor detection error
(cd1)
V V Not-detectable
34
V phase current sensor detection error
(cd2)
V V Not-detectable
35
W phase current sensor detection error
(cd3)
V V Not-detectable
36 Hardware Logic error 0 (Hd0) - cc V V Not-detectable
37 Hardware Logic error 1 (Hd1) - oc V V Not-detectable
38 Hardware Logic error 2 (Hd2) - ov V V Not-detectable
39 Hardware Logic error 3 (Hd3) – occ V V Not-detectable
40 Motor auto tuning error (AuE) V Not-detectable Not-detectable
41 ACI feedback loss (AFE) V Not-detectable Not-detectable
48 ACI Loss V Not-detectable Not-detectable
49 External fault (EF) V Not-detectable Not-detectable
50 Emergency stop (EF1) V Not-detectable Not-detectable
51 base block (bb) V Not-detectable Not-detectable
52 PcodE (Password) V Not-detectable Not-detectable
53 Software code error V V Not-detectable
54 Communication error 1 (cE1) V Not-detectable Not-detectable
55 Communication error 2 (cE2) V Not-detectable Not-detectable
56 Communication error 3 (cE3) V Not-detectable Not-detectable
57 Communication error 4 (cE4) V Not-detectable Not-detectable
58 cE10 (Communication Time Out) V Not-detectable Not-detectable
59 Communication time out (cP10) V Not-detectable Not-detectable
60 Braking Transistor Fault (bf) V Not-detectable Not-detectable
61 Y-Delta connected Error (ydc) V Not-detectable Not-detectable
62 Decel. Energy Backup Error (dEb) V Not-detectable Not-detectable
63 Over Slip Error (oSL) V Not-detectable Not-detectable
64 Electromagnet switch error (ryF) V Not-detectable Not-detectable
72
Channel 1 (STO1~SCM1) internal
hardware error (STL1)
V Not-detectable Not-detectable
73 External safety gate S1 V V Not-detectable
