Chapter 12 Description of Parameter Settings|CFP2000 Series
12.1-09-8
}
return reg_crc; // return register CRC
}
4. Address list
Content Register Function
AC drive parameters GGnnH GG means parameter group, nn means parameter number, for
example, the address of Pr 4-01 is 0401H.
Command write only 2000H
Bit1~0
00B:No function
01B:Stop
10B:Run
11B:JOG
Bit3~2 Reserved
Bit5~4
00B:No function
01B:FWD
10B:REV
11B:Change direction
Bit7~6
00B:1st accel/decel.
01B:2nd accel/decel
10B:3rd accel/decel
11B:4th accel/decel
Bit11~8 000B: master speed
0001B: 1st Step Speed Frequency
0010B: 2nd Step Speed Frequency
0011B: 3rd Step Speed Frequency
0100B: 4th Step Speed Frequency
0101B: 5th Step Speed Frequency
0110B: 6th Step Speed Frequency
0111B: 7th Step Speed Frequency
1000B: 8th Step Speed Frequency
1001B: 9th Step Speed Frequency
1010B: 10th Step Speed Frequency
1011B: 11th Step Speed Frequency
1100B: 12th Step Speed Frequency
1101B: 13th Step Speed Frequency
1110B: 14th Step Speed Frequency
1111B: 15th Step Speed Frequency
Bit12 1: Enable bit06-11 function
Bit14~13
00B:No function
01B:Operated by digital keypad
10B:Operated by Pr.00-21 setting
11B:Change operation source
Bit15 Reserved
2001H Frequency command(XXX.XXHz)
2002H Bit0
1:EF (external fault) on
Bit1
1:Reset
Bit2
1:B.B ON
Bit15~3 Reserved
