Delta VFD007FP4EA-41 - Page 351

Chapter 12 Description of Parameter Settings|CFP2000 Series
12.1-09-9
Content Register Function
Status monitor read
only
2100H
High byte: Warn Code
Low Byte: Error Code
2101H Bit1~0 AC Drive Operation Status
00B: Drive stops
01B: Drive decelerating
10B: Drive standby
11B: Drive operating
Bit2
1：JOG Command
Bit4~3 Operation Direction
00B: FWD run
01B: From REV run to FWD run
10B: REV run
11B: From FWD run to REV run
Bit8
1：Master frequency controlled by communication
interface
Bit9
1：Master frequency controlled by analog signal
Bit10
1：Operation command controlled by
communication interface
Bit11
1：Parameter locked
Bit12
1：Enable to copy parameters from keypad
Bit15~13 Reserved
2102H
Frequency command （XXX.XX Hz）
2103H
Output frequency （XXX.XX Hz）
2104H
Output current（XX.XXA）. When current is higher than
655.35,it will shift decimal as（XXX.XA）. The decimal can refer
to High byte of 211F.
2105H
DC-BUS Voltage （XXX.XV）
2106H
Output voltage（XXX.XV）
2107H Current step number of Multi-Step Speed Operation
2108H Reserved
2109H Counter value
210AH Power Factor Angle (XXX.X)
210BH
Output Torque （XXX.X%）
210CH
Actual motor speed（XXXXXrpm)
210DH Reserved
210EH Reserved
210FH
Power output （X.XXX KWH）
2116H Multi-function display (Pr.00-04)
211BH
Max. operation frequency (Pr.01-00) or Max. user defined
value (Pr.00-26)
When Pr00-26 is 0, this value is equal to Pr01-00 setting
When Pr00-26 is not 0, and the command source is Keypad,
this value = Pr00-24 * Pr00-26 / Pr01-00
When Pr00-26 is not 0, and the command source is 485, this
value = Pr09-10 * Pr00-26 / Pr01-00
211FH High byte: decimal of current value (display)
2200H
Display output current (A). When current is higher than
655.35,it will shift decimal as（XXX.XA）. The decimal can refer
to High byte of 211F.
2201H Display counter value (c)
2202H
Actual output frequency（XXXXXHz）
2203H
DC-BUS voltage（XXX.XV）
2204H
Output voltage（XXX.XV）
2205H
Power angle（XXX.X）
