Chapter 12 Description of Parameter Settings|CFP2000 Series
12.1-09-10
Content Register Function
2206H
Display actual motor speed kW of U, V, W（XXXXXkW）
2207H
Display motor speed in rpm estimated by the drive or encoder
feedback（XXXXXrpm）
2208H
Display positive/negative output torque in %, estimated by the
drive (t0.0: positive torque, -0.0: negative torque)（XXX.X%）
2209H Reserved
220AH
PID feedback value after enabling PID function（XXX.XX%）
220BH
Display signal of AVI analog input terminal, 0-10V corresponds
to 0.00~100.00% (1.) (as Pr. 00-04 NOTE 2)
220CH
Display signal of ACI analog input terminal, 4-V20mA/0-10V
corresponds to 0.00~100.00% (2.) (as Pr. 00-04 NOTE 2)
220DH
Display signal of AUI analog input terminal, -10V~10V
corresponds to -100.00~100% (3.) (as Pr. 00-04 NOTE 2)
220EH
IGBT temperature of drive power module （XXX.X℃）
220FH
The temperature of capacitance （XXX.X℃）
2210H
The status of digital input (ON/OFF), refer to Pr.02-12 (as Pr.
00-04 NOTE 3)
2211H
The status of digital output (ON/OFF), refer to Pr.02-18 (as Pr.
00-04 NOTE 4)
2212H The multi-step speed that is executing (S)
2213H
The corresponding CPU pin status of digital input (d.) (as Pr.
00-04 NOTE 3)
2214H
The corresponding CPU pin status of digital output (O.) (as Pr.
00-04 NOTE 4)
2215H
~
2218H
Reserved
2219H
Display times of counter overload（XXX.XX%）
221AH
GFF（XXX.XX%）
221BH
DCbus voltage ripples（XXX.XV）
221CH PLC register D1043 data (C)
221DH Reserved
221EH User page displays the value in physical measure
221FH
Output Value of Pr.00-05（XXX.XXHz）
2220H Reserved
2221H Reserved
2222H
Fan speed of the drive（XXX%）
2223H Control mode of the drive 0: speed mode 1: torque mode
2224H
Carrier frequency of the drive（XXKHZ）
2225H Reserved
2226H
Drive status
bit 1~0 00b: No direction
01b: Forward
10b: Reverse
bit 3~2 01b: Driver ready
10b: Error
bit 4 0b: Motor drive did not output
1b: Motor drive did output
bit 5 0b: No alarm
1b: Have Alarm
2227H
Drive’s estimated output torque(positive or negative direction)
（XXXX Nt-m）
2228H Reserved
2229H
KWH display（XXXX.X）
