When a motor’s output is disabled, this motor will park freely
Wiring: Fixed Quantity Control can control up to 8 motors. The diagram 12-12 is an example of
controlling 4 motors at the same time.
Diagram 12-12
P02-01~P02-06= 60 61 62 63 64 65 66 67 68
Disable Motor’s Output ALL 1 2 3 4 5 6 7 8
