Chapter 12 Description of Parameter Settings|CFP2000 Series
12.1-13-1
13 Application Parameters by Industry
 This parameter can be set during operation.
Application selection
Factory Setting: 0
Settings
0: Disabled
1: User Parameter
2: Compressor IM
3: Fan
4: Pump
 Settings:
2: Compressor IM
Pr Explanation Settings
00-11 Control of Speed Mode 0: VF (IM V/F control)
00-16
Load Selection
0: Light load
00-17 Carrier Frequency #.#
00-20
Source of Master Frequency
Command（AUTO）
2: External analog input (Pr.03-00)
00-21
Source of the Operation
Command （AUTO）
1: External terminals. Keypad STOP disabled.
00-22
Stop Method
0: Ramp to stop
00-23
Control of Motor Direction
1: Reverse disable
01-00
Max. Operation Frequency
60.00/
50.00
01-01
Output Frequency of Motor 1
60.00/
50.00
01-02
Output Voltage of Motor 1 400.0
01-03
Mid-point Frequency 1 of Motor
1
3.00
01-04
Mid-point Voltage 1 of Motor 1 22.0
01-05
Mid-point Frequency 2 of Motor
1
1.50
01-06
Mid-point Voltage 2 of Motor 1 10.0
01-07
Min. Output Frequency of Motor
1
0.50
01-08
Min. Output Voltage of Motor 1 2.0
01-11
Output Frequency Lower Limit
20（Hz）
01-12
Accel. Time 1
20（s）
01-13
Decel Time 1
20（s）
03-00
Analog Input Selection (AVI) 0: No function
03-01
Analog Input Selection (ACI)
1: Frequency command (speed limit under
torque control mode)
05-01
Full-load Current of Induction
Motor 1(A)
#.##
05-03
Rated Speed of Induction Motor
1 (rpm)
1710
05-04
Pole Number of Induction Motor
1
4
