Chapter 12 Description of Parameter Settings|CFP2000 Series
12.1-13-2
3: Fan
Pr Explanation Settings
00-11
Control of Speed Mode
0(VF)
00-16
Load Selection
1: Normal load
00-17
Carrier Frequency
#.#
00-20
Source of Master Frequency
Command(AUTO)
2: External analog input (Pr.03-00)
00-21
Source of the Operation
Command (AUTO)
1: External terminals. Keypad STOP disabled.
00-22
Stop Method
1: Coast to stop
00-23
Control of Motor Direction
1: Coast to stop
00-30
Source of the Master Frequency
Command(HAND)
0: Digital keypad
00-31
Source of the Operation
Command (HAND)
0: Digital keypad
01-00
Max. Operation Frequency
60.00/
50.00
01-01
Output Frequency of Motor 1
60.00/
50.00
01-02
Output Voltage of Motor 1 400.0
01-03
Mid-point Frequency 1 of Motor
1
3.00
01-04
Mid-point Voltage 1 of Motor 1 22.0
01-05
Mid-point Frequency 2 of Motor
1
1.50
01-06
Mid-point Voltage 2 of Motor 1 10.0
01-07
Min. Output Frequency of Motor
1
0.50
01-08
Min. Output Voltage of Motor 1 2.0
01-10
Output Frequency Upper Limit
50(Hz)
01-11
Output Frequency Lower Limit
35(Hz)
01-12
Accel. Time 1
15(s)
01-13
Decel Time 1
15(s)
01-43 V/f Curve Selection 2: 2
nd
V/F curve
02-05
Multi-function Input Command 5
(MI5)
16: Operation speed command from ACI
03-00
Analog Input Selection (AVI1)
1: Frequency command (speed limit under
torque control mode)
03-01
Analog Input Selection (ACI)
1: Frequency command (speed limit under
torque control mode)
03-28
AVI1 Selection
0(0~10 V)
03-29
ACI Selection
1(0~10 V)
03-31
AFM2 Output Selection
0(0~10 V)
03-50 Analog Input Curve Selection 1: 3 point curve of AVI1
07-06
Restart after Momentary Power
Loss
2: Speed search for minimum output frequency
07-11
Number of Times of Auto Restart
After Fault
5
07-33 Auto restart internal of Fault 60(s)
