Delta VFD220VL43C-J User Manual

Chapter 4 Description of Parameters | VFD-VJ
4-19
04 Communication Parameters  You can set this parameter during operation.
Pr.
Explanation
Settings
Factory
Setting
VF
FOCPG
FOCPM

04-00
Communication
address
1~254
1
○ ○ ○

04-01
COM transmission
speed
4.8~115.2 Kbps
19.2
○ ○ ○

04-02
COM transmission
fault treatment
0: Warn and continue operation
1: Warn and ramp to stop
2: Warn and coast to stop
3: No warning and continue operation
3
○ ○ ○

04-03
COM time-out
detection
0.0~100.0 sec.
0.0
○ ○ ○

04-04
COM1
communication
protocol
0: 7N1 (ASCII)
1: 7N2 (ASCII)
2: 7E1 (ASCII)
3: 7O1 (ASCII)
4: 7E2 (ASCII)
5: 7O2 (ASCII)
6: 8N1 (ASCII)
7: 8N2 (ASCII)
8: 8E1 (ASCII)
9: 8O1 (ASCII)
10: 8E2 (ASCII)
11: 8O2 (ASCII)
12: 8N1 (RTU)
13: 8N2 (RTU)
14: 8E1 (RTU)
15: 8O1 (RTU)
16: 8E2 (RTU)
17: 8O2 (RTU)
13
○ ○ ○

04-05
Delay time of
communication
response
0.0~200.0 ms 2.0
○ ○ ○
04-06
Main frequency of
the communication
0.00~ 599.00 Hz 60.00
○ ○ ○

04-07
Block transfer 1
0.00~655.35
0.00
○ ○ ○

04-08 Block transfer 2
0.00~655.35
0.00
○ ○ ○

04-09 Block transfer 3
0.00~655.35
0.00
○ ○ ○

04-10
Block transfer 4
0.00~655.35
0.00
○ ○ ○

04-11 Block transfer 5
0.00~655.35
0.00
○ ○ ○

04-12 Block transfer 6
0.00~655.35
0.00
○ ○ ○

04-13
Block transfer 7
0.00~655.35
0.00
○ ○ ○

04-14 Block transfer 8
0.00~655.35
0.00
○ ○ ○

04-15 Block transfer 9
0.00~655.35
0.00
○ ○ ○

04-16
Block transfer 10
0.00~655.35
0.00
○ ○ ○
04-17
CANopen slave
address
0: Disable
1~127
0
○ ○ ○
04-18
CANopen speed 0: 1 Mbps 0
○ ○ ○
