Chapter 10 Digital KeypadMS300 (High Speed Model)
10-4
Pr. 13-00=3 is Fan application, keypad will display FAn
Pr. 13-00=4 is Pump application, keypad will display PUMP
Pr. 13-00=5 is Conveyor application, keypad will display CnYr
Pr. 13-00=6 is Machine tool, keypad will display CnC
Pr. 13-00=7 is Packing application, keypad will display PAC
Pr. 13-00=8 is Textiles application, keypad will display tiLE
When Pr. 13-00≠0, the corresponding parameters will be shown in the APP page according to
the setting of Pr. 13-00. Then in each selected application, user can view the parameters by pressing
Enter button. (If Pr.13-00=1 and no parameters are set in Pr.13-01~13-50, the user can not enter
USEr page.) The parameter setting in APP is the same as for other parameters groups: use up and
left/down key to set the parameter value.
Please follow the setting process below to set the User Defined application selection (Pr.13-00=1):
Set Pr.13-00=1
Activate User Defined
application selection
Set Pr.13-01~13-50 User
Defined parameters by
order
When finishing setting, press
MODE button to APP page, and
then press ENTER to USEr page.
Press ENTER again, the user
defined parameters will appear
Use up and down key
to select defined
parameters, and
press ENTER to
check the setting
If the user wants to change
the User Defined parameters,
then the user needs to go
back to parameter group 13 to
modif
If the user wants to remove the
User Defined parameters, then
go back to parameter group 13,
and set the parameter as 0.00
from the last defined parameter
by sequence
To Next Page
