Chapter 11 Summary of Parameter SettingsMS300 (High Speed Model)
11-9
02 Digital Input / Output Parameters
Pr. Explanation Settings
Factory
Setting
02-00 2-wire / 3-wire operation control
0: No function
1: 2-wire mode 1, power on for operation control
(M1: FWD / STOP, M2: REV / STOP)
2: 2-wire mode 2, power on for operation control
(M1: RUN / STOP, M2: REV / FWD)
3: 3-wire, power on for operation control
(M1: RUN, M2: REV / FWD, M3: STOP)
4: 2-wire mode 1，fast start up
(M1: FWD / STOP, M2: REV / STOP)
5: 2-wire mode 2，fast start up
(M1: RUN / STOP, M2: REV / FWD)
6: 3-wire，fast start up
(M1: RUN, M2: REV / FWD, M3: STOP)
IMPORTANT
1. In fast start up function, terminal output will
keep in ready status, drive will response to the
command immediately.
2. When using fast start up function, the output
terminal will have higher voltage potentially.
1
02-01
Multi-function input command 1
(MI1)
0: No function
0
1: Multi-stage speed command 1 / multi-stage
02-02
Multi-function input command 2
(MI2)
position command 1
0
2: Multi-stage speed command 2 / multi-stage
02-03
Multi-function input command 3
(MI3)
position command 2
1
3: Multi-stage speed command 3 / multi-stage
02-04
Multi-function input command 4
(MI4)
position command 3
2
4: Multi-stage speed command 4 / multi-stage
02-05
Multi-function input command 5
(MI5)
position command 4
3
5: Reset
02-06
Multi-function input command 6
(MI6)
6: JOG operation (By KPC-CC01 or external
4
control)
02-07
Multi-function input command 7
(MI7)
7: Acceleration / deceleration speed inhibit
0
8: The 1
st
, 2
nd
acceleration / deceleration time
selection
9: The 3
rd
, 4
th
acceleration / deceleration time
selection
10: EF Input (Pr. 07-20)
11: B.B input from external (Base Block)
