Chapter 11 Summary of Parameter SettingsMS300 (High Speed Model)
11-10
Pr. Explanation Settings
Factory
Setting
12: Output stop
13: Cancel the setting of auto accel. / decel. time
15: Rotating speed command from AVI
16: Rotating speed command from ACI
18: Forced to stop (Pr. 07-20)
19: Digital up command
20: Digital down command
22: Clear counter command
23: Input the counter value (MI6)
24: FWD JOG command
25: REV JOG command
28: Emergency stop (EF1)
29: Signal confirmation for Y-connection
30: Signal confirmation for -connection
38: Disable EEPROM write function
40: Force coast to stop
41: HAND switch
42: AUTO switch
49: Drive enable
50: Master dEb input
51: Selection for PLC mode bit 0
52: Selection for PLC mode bit 1
53: Trigger CANopen quick stop
56: Local / Remote Selection
81: Zero point position signal input of simple
positioning
83: Multi-motors (IM) selection bit 0
84: Multi-motors (IM) selection bit 1
02-09
UP / DOWN key mode
0: UP / DOWN by the accel. / decel. time
1: UP / DOWN constant speed (Pr. 02-10)
2: Pulse command (Pr. 02-10)
3: External terminals UP / DOWN mode
0
02-10
Constant speed. The accel. / decel.
speed of the UP / DOWN Key
0.001~1.000 Hz / ms 0.001
02-11 Digital input response time 0.000~30.000 sec. 0.005
02-12
Digital input mode selection 0000h~FFFFh (0: N.O.; 1: N.C.) 0000
02-13 Multi-function output 1 RY1 0: No function 11
02-16 Multi-function output 2 (MO1) 1: Indication during RUN 0
02-17 Multi-function output 3 (MO2) 2: Operation speed attained 0
