Chapter 11 Summary of Parameter SettingsMS300 (High Speed Model)
11-11
Pr. Explanation Settings
Factory
Setting
3: Desired frequency attained 1 (Pr. 02-22)
4: Desired frequency attained 2 (Pr. 02-24)
5: Zero speed (Frequency command)
6: Zero speed, include STOP (Frequency
command)
7: Over torque 1 (Pr. 06-06~06-08)
8: Over torque 2 (Pr. 06-09~06-11)
9: Drive is ready
10: Low voltage warning (LV) (Pr. 06-00)
11: Malfunction indication
13: Overheat warning (Pr. 06-15, OH1)
14: Software brake signal indication (Pr. 07-00)
17: Count value attained, does not return to 0
(Pr. 02-20)
18: Count value attained, returns to 0 (Pr. 02-19)
19: External interrupt B.B. input (Base Block)
20: Warning output
21: Over voltage warning
22: Over-current stall prevention warning
23: Over-voltage stall prevention warning
24: Operation source
25: Forward command
26: Reverse command
29: Output when frequency ≥ Pr. 02-34
30: Output when frequency
< Pr. 02-34
31: Y-connection for the motor coil
32: △-connection for the motor coil
33: Zero speed (actual output frequency)
34: Zero speed include stop (actual output
frequency)
35: Error output selection 1 (Pr. 06-23)
36: Error output selection 2 (Pr. 06-24)
37: Error output selection 3 (Pr. 06-25)
38: Error output selection 4 (Pr. 06-26)
40: Speed attained (including Stop)
43: Motor actual speed output
< Pr. 02-47
44: Low current output (use with Pr. 06-71~06-73)
45: UVW magnetic contactor ON / OFF switch
46: Master dEb signal output
50: Output for CANopen control
