Delta VFD9A0MS43ANSHA User Manual

Chapter 12 Description of Parameter SettingsMS300 (High Speed Model)
12-09-5
RTU mode:
Command Message: Response Message
Address 01H Address 01H
Function 03H Function 03H
Starting data register
21H
Number of register
(count by Byte)
04H
02H
Number of register
(count by word)
00H
Content of register
address 2102H
17H
02H 70H
CRC CHK Low 6FH
Content of register
address 2103H
00H
CRC CHK High F7H 00H
CRC CHK Low FEH
CRC CHK High 5CH
06H: single write, write single data to register.
Example: writing data 6000 (1770H) to register 0100H. AMD address is 01H.
ASCII mode:
Command Message: Response Message
STX ‘:’ STX ‘:’
Address
‘0’
Address
‘0’
‘1’ ‘1’
Function
‘0’
Function
‘0’
‘6’ ‘6’
Target register
‘0’
Target register
‘0’
‘1’ ‘1’
‘0’ ‘0’
‘0’ ‘0’
Register content
‘1’
Register content
‘1’
‘7’ ‘7’
‘7’ ‘7’
‘0’ ‘0’
LRC Check
‘7’
LRC Check
‘7’
‘1’ ‘1’
END
CR
END
CR
LF LF
RTU mode:
Command Message: Response Message
Address 01H Address 01H
Function 06H Function 06H
Target register
01H
Target register
01H
00H 00H
Register content
17H
Register content
17H
70H 70H
CRC CHK Low
CRC CHK High
86H
CRC CHK Low
CRC CHK High
86H
22H 22H
10H: write multiple registers (write multiple data to registers) (at most 20 sets of data can be
written simultaneously)
Example: Set the multi-stage speed of AC motor drive (address is 01H):
Pr. 04-00 = 50.00 (1388H), Pr. 04-01 = 40.00 (0FA0H)
