Page #269 background imageLoading...
Page #269 background image
Chapter 12 Description of Parameter SettingsMS300 (High Speed Model)
12-09-8
4. Address list
Content Register Function
AC motor drive
parameters
GGnnH
GG means parameter group, nn means parameter number,
for example, the address of Pr. 04-01 is 0401H.
Command write only
2000H
bit 1~0
00B: No function
01B: Stop
10B: Run
11B: JOG + RUN
bit 3~2 Reserved
bit 5~4
00B: No function
01B: FWD
10B: REV
11B: Change direction
bit 7~6
00B: 1
st
accel. / decel.
01B: 2
nd
accel. / decel.
10B: 3
rd
accel. / decel.
11B: 4
th
accel. / decel.
bit 11~8
000B: Master speed
0001B: 1
st
Stage speed frequency
0010B: 2
nd
Stage speed frequency
0011B: 3
rd
Stage speed frequency
0100B: 4
th
Stage speed frequency
0101B: 5
th
Stage speed frequency
0110B: 6
th
Stage speed frequency
0111B: 7
th
Stage speed frequency
1000B: 8
th
Stage speed frequency
1001B: 9
th
Stage speed frequency
1010B: 10
th
Stage speed frequency
1011B: 11
th
Stage speed frequency
1100B: 12
th
Stage speed frequency
1101B: 13
th
Stage speed frequency
1110B: 14
th
Stage speed frequency
1111B: 15
th
Stage speed frequency
bit 12 1: Enable 2000H bit 6~bit 11 function
bit
14~13
00B: No function
01B: Operated by digital keypad
10B: Operated by Pr. 00-21 setting
11B: Change operation source
bit 15 Reserved
2001H Frequency command (XXX.XX Hz)
2002H
bit 0 1: EF (external fault) on
bit 1 1: Reset
bit 2 1: B.B ON
bit 15~3 Reserved
2100H
High byte: Warn code
Low Byte: Error code
bit 1~0
AC motor drive operation status
00B: Drive stops
01B: Drive decelerating
10B: Drive standby
11B: Drive operating
Status monitor read
only
2101H bit 2 1: JOG command
bit 4~3
Operation direction
00B: FWD run
01B: From REV run to FWD run
10B: REV run
11B: From FWD run to REV run
