Chapter 12 Description of Parameter SettingsMS300 (High Speed Model)
12-09-9
Content Register Function
bit 8
1: Master frequency controlled by communication
interface
bit 9 1: Master frequency controlled by analog signal
bit 10
1: Operation command controlled by
communication interface
bit 11 1: Parameter locked
bit 12 1: Enable to copy parameters from keypad
bit
15~13
Reserved
2102H Frequency command (XXX.XX Hz)
2103H Output frequency (XXX.XX Hz)
2104H
Output current (XX.XX A). When current is higher than
655.35, it will shift decimal as (XXX.X A). The decimal can
refer to High byte of 211F.
2105H DC-BUS voltage (XXX.X V)
2106H Output voltage (XXX.X V)
2107H Current step number of multi-stage speed operation
2108H Reserved
2109H Counter value
210AH Power factor angle (XXX.X)
210BH Output torque (XXX.X %)
210CH Actual motor speed (XXXXX rpm)
210DH Number of PG feedback pulses (0~65535)
210EH Number of PG2 pulse commands (0~65535)
210FH Power output (X.XXX KWH)
2116H Multi-function display (Pr. 00-04)
211BH
Max. operation frequency (Pr. 01-00) or Max. user defined
value (Pr. 00-26)
When Pr. 00-26 is 0, this value is equal to Pr. 01-00 setting
When Pr. 00-26 is not 0, and the command source is Keypad,
this value = Pr. 00-24 * Pr. 00-26 / Pr. 01-00
When Pr. 00-26 is not 0, and the command source is 485, this
value = Pr. 09-10 * Pr. 00-26 / Pr. 01-00
211FH High Byte: decimal of current value (display)
2200H
Display output current (A). When current is higher than
655.35, it will shift decimal as (XXX.X A). The decimal can
refer to High Byte of 211F.
2201H Display counter value (c)
2202H Actual output frequency (XXXXX Hz)
2203H DC-BUS voltage (XXX.X V)
2204H Output voltage (XXX.X V)
2205H Power angle (XXX.X)
2206H Display actual motor speed kW of U, V, W (XXXXX kW)
2207H
Display motor speed in rpm estimated by the drive or encoder
feedback (XXXXX rpm)
2208H
Display positive / negative output torque in %, estimated by
the drive (t0.0: positive torque, -0.0: negative torque)
(XXX.X %)
2209H Display PG feedback (as Pr. 00-04 NOTE 1)
220AH PID feedback value after enabling PID function (XXX.XX %)
220BH Reserved
220CH
Display signal of ACI analog input terminal, 4-V 20 mA / 0-10
V corresponds to 0.00~100.00 % (2.) (as Pr. 00-04 NOTE 2)
220DH Reserved
220EH IGBT temperature of drive power module (XXX.X °C)
220FH The temperature of capacitance (XXX.X °C)
