Chapter 12 Description of Parameter SettingsMS300 (High Speed Model)
12-13-1
13 Macro / User Define Macro
Application Selection
Factory Setting: 00
Settings 00: Disabled
01: User parameter
09: PCB Machine
Note: After selecting the macro, some of default values will be adjusted automatically according
to the application selection.
Group setting 09: PCB Machine
The following table of contents is the relevant application parameters used for PCB Machine
settings.
Pr. Explanation Settings
00-11 Control of speed mode 0 (VF)
00-20 Source of the master frequency command (AUTO) 2 (External analog input)
00-21 Source of the operation command (AUTO) 1 (External terminals)
00-23 Control of motor direction 1 (Disable reverse)
01-00 Max. operation frequency of motor 1 1500 (Hz)
01-01 Output frequency of motor 1 800 (Hz)
01-02 Output voltage of motor 1 380 (V)
01-03 Mid-point frequency 1 of motor 1 20 (Hz)
01-04 Mid-point voltage 1 of motor 1 22 (V)
01-05 Mid-point frequency 2 of motor 1 5 (Hz)
01-06 Mid-point voltage 2 of motor 1 4 (V)
01-07 Min. output frequency of motor 1 0.0
01-08 Min. output voltage of motor 1 0.0
01-12 Accel. time 1 4 (s)
01-13 Decel. time 1 3 (s)
02-13 Multi-function output 1 RY1 11 (Malfunction indication)
02-16 Multi-function output 3 (MO1) 1 (Operation Indication)
02-17 Multi-function output 4 (MO2) 2 (Operation speed attained)
03-00 Analog input selection (AVI) 1 (Frequency command)
06-01 Over-voltage stall prevention 0 (Disabled)
06-03 Over-current stall prevention during acceleration 0 (Disabled)
06-04 Over-current stall prevention during operation 0 (Disabled)
06-05
Accel. / Decel. time selection of stall prevention at
constant speed
0 (Disabled)
06-06 Over-torque detection selection (motor1)
2 (Stop after Over-torque detection
during constant speed operation)
06-07 Over-torque detection level (motor 1) Factory default setting
06-08 Over-torque detection time (motor 1) Factory default setting
