Delta VFD9A0MS43ANSHA User Manual

Chapter 7 Optional Accessories  MS300 (High Speed Model)
7-8
230V / 50~60Hz MS Series Heavy Duty Input AC Reactor
Model
Rated Current
ND / HD (A
rms
)
Saturation
ND / HD
Current (A
rms
)
Input/ Output
Reactor (mH)
Input Reactor
Delta Part #
DC Reactor
(mH)
DC Reactor
Delta Part #
VFD25AMS23ANSHA
VFD25AMS23ENSHA
25 50 0.32 DR033AP320 1.172 DR025D0117
VFD33AMS23ANSHA
VFD33AMS23ENSHA
33 66 0.216 DR049AP215 0.851 DR033DP851
VFD49AMS23ANSHA
VFD49AMS23ENSHA
46 92 0.216 DR049AP215 0.574 DR049DP574
VFD65AMS23ANSHA
VFD65AMS23ENSHA
65 130 0.169 DR075AP170 0.432 DR065DP432
460V / 3-Phase Heavy Duty
460V/ 50~60Hz MS Series Heavy Duty Input AC Reactor
Model
Rated
Current
ND / HD
(A
rms
)
Saturation
ND / HD
Current (A
rms
)
Input/ Output
Reactor (mH)
Input Reactor
Delta Part #
DC Reactor
(mH)
DC Reactor
Delta Part #
VFD4A2MS43AFSHA
VFD4A2MS43ANSHA
VFD4A2MS43ENSHA
4.2 8.4 4.05 DR006A0405 14.031 DR004D1403
VFD5A5MS43AFSHA
VFD5A5MS43ANSHA
VFD5A5MS43ENSHA
5.5 11 2.7 DR009A0270 9.355 DR006D0935
VFD9A0MS43AFSHA
VFD9A0MS43ANSHA
VFD9A0MS43ENSHA
9 18 2.315 DR010A0231 5.345 DR010D0534
VFD13AMS43AFSHA
VFD13AMS43ANSHA
VFD13AMS43ENSHA
13 26 1.174 DR018A0117 3.119 DR018D0311
VFD17AMS43AFSHA
VFD17AMS43ANSHA
VFD17AMS43ENSHA
17 34 0.881 DR024AP881 3.119 DR018D0311
VFD25AMS43AFSHA
VFD25AMS43ANSHA
VFD25AMS43ENSHA
25 50 0.66 DR032AP660 2.338 DR024D0233
VFD32AMS43AFSHA
VFD32AMS43ANSHA
VFD32AMS43ENSHA
32 64 0.639 DR038AP639 1.754 DR032D0175
VFD38AMS43AFSHA
VFD38AMS43ANSHA
VFD38AMS43ENSHA
38 76 0.541 DR045AP541 1.477 DR038D0147
VFD45AMS43AFSHA
VFD45AMS43ANSHA
VFD45AMS43ENSHA
45 90 0.405 DR060AP405 1.247 DR045D0124
