Chapter 7 Optional AccessoriesMS300 (High Speed Model)
7-13
Screw Location Torque
Terminal 10.63~12.4 kg-cm / [12.24~14.28 lb-in.] / [1.2~1.4 Nm]
Input AC reactor
Delta part #
A B C D1*D2 H G G1 Q M PE D
DR038AP639 180 195 160 6*12 115 85 122 16 1.2~1.4 M4
DR045AP541 235 235 145 7*13 85 / 176 16 1.2~1.4 M6
Unit: mm
