Deltech SPX FLOW - Air-Cooled Unit General Arrangement Drawings

8
SPECIFICATIONS: AIR-COOLED UNITS
General Arrangement Drawing:
Model HGEN600A
MODEL
DIMENSIONS, INCHES (MM)
INLET/OUTLET
CONNECTIONS
WEIGHT
Lb. (kg)
A B C D E F G H J K L
HGEN600A
31.94
(811.2)
21.75
(552.4)
50.44
(1281.3)
4.86
(123.5)
7.94
(201.6)
3.23
(82.0)
26.74
(679.2)
20.24
(514)
4.18
(106.2)
40.94
(1040)
49.26
(1251.2)
2" NPT
344
(156)
DRIED AIR OUTLET
WETTED AIR INLET
AIR FLOW
COOLING
HOLE FOR MAIN POWER
DRAIN OUTLET
5-Ø10 MOUNTING HOLES
FOOT PRINT
D E
G
B
A
H
F
ON/OFF SWITCH, PCB
C
JK
L
FRONT VIEW REAR VIEWRIGHT SIDE VIEW
TOP VIEW
