7
Model HGEN600 HGEN800 HGEN1000 HGEN1200
Air System Data
Rated Air Flow at 100°F & 100 psig Inlet, 100°F Ambient (scfm) 60 Hz 600 800 1000 1200
Minimum / Maximum Inlet Compressed Air Pressure 43.5 / 232 psig (3 / 16 barg)
Minimum / Maximum Inlet Compressed Air Temperature 45° / 120°F (7° / 49°C)
Minimum / Maximum Ambient Temperature 37° / 109°F (3° / 43°C)
Outlet Air Temperature (nominal at rated conditions) 86°F (30°C)
Refrigeration System Data
Compressor Type Hermetic Reciprocating
Refrigeration Compressor Horsepower 3 US RT 4 US RT 5 US RT 6 US RT
Refrigeration Capacity @ Rated Flow (BTU/hr)* 60 Hz 34,080 48,120 60,380 76,870
Refrigerant Type R-407C
Refrigerant Charge See Data Tag on Dryer
Suction Pressure Setting 60 psig (4.1 barg)
Compressor Pressure Switch Setting (cut out / cut in) High, a-c 398 psig / manual reset (27.4 barg / manual reset)
High, w-c 313 psig / manual reset (21.6 barg / manual reset)
Air-Cooled Condensers
Air Flow Across Condenser (cfm) 60 Hz 2,825 4,120 4,120 4,120
Condenser Fan Switch Setting (cut in / cut out) Fan 1 / Fan 2 299 / 213 psig (20.6 / 14.7 barg)
Water-Cooled Condensers
Water Regulating Valve Setting 220 psig (15.2 barg)
Minimum Water Pressure Differential 40 psig (2.8 barg)
Cooling Water Flow with 85°F (gpm)* 60 Hz 6.15 8.19 10.24 12.29
Electrical Data
Nominal Voltage 460/3/60
Voltage Range 414 - 506
Input Power @ Rated Flow (watts) * 3,800 5,400 6,600 8,660
Minimum Circuit Ampacity 7.8 10.1 12.6 15.9
Maximum Overcurrent Protector (amps) 15 20 20 25
Compressor Rated Load Amps 5.7 7.3 9.4 12.0
Compressor Locked Rotor Amps 30 42 67 80
NOTES
* 60 Hz: 35°F Evaporator & 100°F Ambient; 50 Hz: 35°F Evaporator & 77°F Ambient
SPECIFICATIONS: ENGINEERING DATA TABLE
