DISASSEMBLY
• Disassemble in order of the arrow in the following gure.
• In the case of the re-assembling, assemble it in order of the reverse of the following ow.
• In the case of the reassembling, observe "Caution concerning disassembly and assembly!".
• If wire bundles are untied or moved to perform adjustment or replace parts etc., be sure to rearrange them neatly as
they were originally bundled or placed afterward.
Otherwise, incorrect arrangement can be a cause of noise generation.
FRONT PANEL ASSY
Refer to "DISASSEMBLY
1. FRONT PANEL ASSY"
and "EXPLODED VIEW"
FRONT PCB
(Ref. No. of EXPLODED VIEW : C1-1)
POWER KNOB PCB
(Ref. No. of EXPLODED VIEW : C1-2)
HEADPHONE PCB
(Ref. No. of EXPLODED VIEW : C1-3)
USB PCB
(Ref. No. of EXPLODED VIEW : C1-4)
MIC PCB
(Ref. No. of EXPLODED VIEW : C1-5)
F-HDMI PCB
(Ref. No. of EXPLODED VIEW : C3-2)
RADIATOR ASSY
Refer to "DISASSEMBLY
3. RADIATOR ASSY"
and "EXPLODED VIEW"
MAIN PCB
(Ref. No. of EXPLODED VIEW : C2-1)
SMPS PCB
Refer to "DISASSEMBLY
4. SMPS PCB"
and "EXPLODED VIEW"
SMPS PCB
(Ref. No. of EXPLODED VIEW : C4-1)
REGULATOR PCB
Refer to "DISASSEMBLY
5. REGULATOR PCB"
and "EXPLODED VIEW"
REGULATOR PCB
(Ref. No. of EXPLODED VIEW : C4-2)
TRANS POWER
Refer to "DISASSEMBLY
6. TRANS POWER"
and "EXPLODED VIEW"
TRANS POWER
(Ref. No. of EXPLODED VIEW : C6 )
DIGITAL PCB ASSY
Refer to "DISASSEMBLY
2. DIGITAL PCB ASSY"
and "EXPLODED VIEW"
DIGITAL PCB
(Ref. No. of EXPLODED VIEW : C3-1)
TUNER PCB
(Ref. No. of EXPLODED VIEW : C2-5)
TOP CABINET
