Denon AVR-1613 Service Manual

23
3. Remote ID Setup mode
3.1. Specications
When using multiple DENON AV receivers in the same room, make this setting so that only the desired AV receiver
operates.
3.2. Setting the AV receivers
Starting up:
Press and hold both "STATUS" and "DIMMER" buttons for over 3 second with the power turned on.
(1) When Remote ID Setup mode is started, the following is displayed.
FLD
R E M O T E I D ?
(2) Press the QUICK SELECT 1 - 4 button that corresponds to the number you want to set.
Button FL Display
QUICK SELECT 1
R E M O T E I D 1
QUICK SELECT 2
R E M O T E I D 2
QUICK SELECT 3
R E M O T E I D 3
QUICK SELECT 4
R E M O T E I D 4
(3) Turn off the power using
X
button.
(4) Turn on the power using
X
button.
b
When Remote ID Setup mode is running, operations other than the QUICK SELECT 1 - 4 buttons or
X
buttons on
the main unit are not received.
b
For the remote control that is supplied with this unit, you cannot change the REMOTE ID.
NOTE:
If the IDs do not match, "AVAMP
z
" (
z
is the main unit's remote control ID) appears on the display when the remote
control unit is operated.

Denon AVR-1613 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby TrueHD, DTS Neo:6, DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	150.8 mm
Width	434.3 mm
Height	328.9 mm
Weight	8300 g
