Denon AVR-1613 Service Manual

157
MAIN PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
Q5101 943211500150S
PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5102 943211500150S
PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5103 943213500150S
NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA *
Q5104 90M-HT800120R
T.R,BIAS HVTKTC3114A
Q5105 90M-HT400490R T.R,POWER HVT2SD2390
Q5106 90M-HT200440R T.R,POWER HVT2SB1560
Q5107 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5108 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5201 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5202 943211500150S
PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5203 943213500150S
NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA *
Q5204 90M-HT800120R
T.R,BIAS HVTKTC3114A
Q5205 90M-HT400490R T.R,POWER HVT2SD2390
Q5206 90M-HT200440R T.R,POWER HVT2SB1560
Q5207 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5208 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5301 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5302 943211500150S
PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5303 943213500150S
NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA *
Q5304 90M-HT800120R
T.R,BIAS HVTKTC3114A
Q5305 90M-HT400490R T.R,POWER HVT2SD2390
Q5306 90M-HT200440R T.R,POWER HVT2SB1560
Q5307 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5308 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5401 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5402 943211500150S
PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5403 943213500150S
NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA *
Q5404 90M-HT800120R
T.R,BIAS HVTKTC3114A
Q5405 90M-HT400490R T.R,POWER HVT2SD2390
Q5406 90M-HT200440R T.R,POWER HVT2SB1560
Q5407 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5408 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5501 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5502 943211500150S
PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5503 943213500150S
NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA *
Q5504 90M-HT800120R
T.R,BIAS HVTKTC3114A
Q5505 90M-HT400490R T.R,POWER HVT2SD2390
Q5506 90M-HT200440R T.R,POWER HVT2SB1560
Q5507 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5508 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5601 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C *
Q5602 943213500160S
T.R,RT1N237C(2.2K-47K) CVTRT1N237C *
Q5603 943213500160S
T.R,RT1N237C(2.2K-47K) CVTRT1N237C *
Q5604 943213500160S
T.R,RT1N237C(2.2K-47K) CVTRT1N237C *
Q5701 943212500020S
HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5702 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5703 943214500040S
HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5704 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5705 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5706 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5707 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5708 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
D5102 90M-HD302390R DIODE,ZENER,1/2W,3.3V CVDZJ3.3BT
D5103 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5104 90M-HD302390R DIODE,ZENER,1/2W,3.3V CVDZJ3.3BT
D5105 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5106 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5202 90M-HD302390R DIODE,ZENER,1/2W,3.3V CVDZJ3.3BT
D5203 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5204 90M-HD302390R DIODE,ZENER,1/2W,3.3V CVDZJ3.3BT
D5205 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5206 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5302 90M-HD302390R DIODE,ZENER,1/2W,3.3V CVDZJ3.3BT

Denon AVR-1613 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby TrueHD, DTS Neo:6, DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	150.8 mm
Width	434.3 mm
Height	328.9 mm
Weight	8300 g
