Denon AVR-1613 Service Manual

113
Ref. No. Part No. Part Name Remarks Q'ty New
SCREWS
S1 nsp SCREW, SPECIAL CHD1A012ZR 15
S2 nsp SCREW CTWS3+10GR 1
S3 nsp SCREW CTB3+6JR 13
S4 nsp SCREW CTB3+10JR 19
S5 nsp SCREW CTBD3+8JFZR 15
S6 nsp SCREW BK CTBD4+8JFZR 6
S6 nsp SCREW SP CTBD4+8JFN 6
S7 nsp SCREW CTBD3+6FFZR 12
S8 nsp SCREW CTW3+8JR 14
S9 nsp SCREW CTW3+12JR 2
S10 nsp SCREW,TRANS CHDR1A023R 4
S11 nsp SCREW
BK CTB3+8JFZR 3
S11 nsp SCREW
SP CTB3+8JFN 3
S12 nsp SCREW BK CTBD3+8JFZR 6
S12 nsp SCREW SP CTBD3+8JFN 6
S13 nsp SCREW CTB3+6FR 4
S14 nsp SCREW CTW3+6JR 2
S15 nsp SCREW,SPECIAL CHD4A012R 3
WIRES
H1 943606501550S CARD,CABLE CWC5C4A25B180B10 1
H2 943606501560S CARD,CABLE CWC5F4A23A270B08 1
H3 nsp WIRE,ASS'Y CWE8102050RR 1

Denon AVR-1613 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby TrueHD, DTS Neo:6, DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	150.8 mm
Width	434.3 mm
Height	328.9 mm
Weight	8300 g
