Denon AVR-1613 Service Manual

159
Ref. No. Part No. Part Name Remarks Q'ty New
R5213 00MGD05272160
RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T
R5214 00MGD05561160 RES,CARBON(1/5W,560ohm,J) CRD20TJ561T
R5215 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT
R5216 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT
R5217 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT
R5218 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT
R5219 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5220 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5221 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5222 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5223 RES,CARBON(1/5W,820Kohm,J) CRD20TJ824T
R5224 00MGD05274160 RES,CARBON(1/5W,270Kohm,J) CRD20TJ274T
R5225 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
z
R5226 943252100130S
PTCTHEMISTORS,CHIP(95C) CRTB59641A0095 *
R5227 00MGD05562160
RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T
R5229 00MGD05153160 RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T
R5230 00MGD05223160 RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T
R5231 00MGD05223160 RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T
R5232 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R5301 00MGD05104160 RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T
R5302 00MGD05681160 RES,CARBON(1/5W,680ohm,J) CRD20TJ681T
R5303 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
R5304 00MGD05183160 RES,CARBON(1/5W,18Kohm,J) CRD20TJ183T
R5305 00MGD05122160 RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T
R5306 nsp RES,M-OXIDEFILM(1W/1.2Kohm) CRG1SANJ122RT
R5307 00MGD05221160 RES,CARBON(1/5W,220ohm,J) CRD20TJ221T
R5308 00MGD05474160 RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T
R5309 00MGD05333160 RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T
R5310 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT
R5311 00MGD05224160 RES,CARBON(1/5W,220Kohm,J) CRD20TJ224T
R5312 00MGD05224160 RES,CARBON(1/5W,220Kohm,J) CRD20TJ224T
R5313 00MGD05272160 RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T
R5314 00MGD05561160 RES,CARBON(1/5W,560ohm,J) CRD20TJ561T
R5315 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT
R5316 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT
R5317 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT
R5318 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT
R5319 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5320 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5321 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5322 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5323 RES,CARBON(1/5W,820Kohm,J) CRD20TJ824T
R5324 00MGD05274160 RES,CARBON(1/5W,270Kohm,J) CRD20TJ274T
R5325 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
z
R5326 943252100130S
PTCTHEMISTORS,CHIP(95C) CRTB59641A0095 *
R5327 00MGD05562160
RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T
R5329 00MGD05153160 RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T
R5330 00MGD05223160 RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T
R5331 00MGD05223160 RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T
R5332 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R5401 00MGD05104160 RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T
R5402 00MGD05681160 RES,CARBON(1/5W,680ohm,J) CRD20TJ681T
R5403 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
R5404 00MGD05183160 RES,CARBON(1/5W,18Kohm,J) CRD20TJ183T
R5405 00MGD05122160 RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T
R5406 nsp RES,M-OXIDEFILM(1W/1.2Kohm) CRG1SANJ122RT
R5407 00MGD05221160 RES,CARBON(1/5W,220ohm,J) CRD20TJ221T
R5408 00MGD05474160 RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T
R5409 00MGD05333160 RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T
R5410 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT
R5411 00MGD05224160 RES,CARBON(1/5W,220Kohm,J) CRD20TJ224T
R5412 00MGD05224160 RES,CARBON(1/5W,220Kohm,J) CRD20TJ224T
R5413 00MGD05272160 RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T
R5414 00MGD05561160 RES,CARBON(1/5W,560ohm,J) CRD20TJ561T
R5415 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT
R5416 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT
R5417 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT

Denon AVR-1613 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby TrueHD, DTS Neo:6, DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	150.8 mm
Width	434.3 mm
Height	328.9 mm
Weight	8300 g
