Denon AVR-1613 Service Manual

162
Ref. No. Part No. Part Name Remarks Q'ty New
C5706 943134010460S
CAP,ELECT(30X35)WITHOUTPLATEONTHETOP CCET63VKL5682NKZ
C5707 943134010470S CAP,ELECT(50V/0.1uF) CCEA1HH0R1T
C5708 943134010480S CAP,ELECT(100V/100uF) CCEA2AH101E
C5710 nsp CAP,SEMICONDUCTOR CCFT1H104ZF
C5711 943134010660S CAP,ELECT(6.3V/470uF) CCEA0JH471T
C5712 nsp CAP,SEMICONDUCTOR CCFT1H104ZF
C5713 943134010660S CAP,ELECT(6.3V/470uF) CCEA0JH471T
C5716 963134010980S CAP,ELECT(16V/47uF) CCEA1CH470T
C5717 00D9430175108 CAP,ELECT(50V/10uF) CCEA1HH100T
C5718 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT
C5719 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT
C5720 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT
C5721 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT
C5722 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT
C5723 00D9430175108 CAP,ELECT(50V/10uF) CCEA1HH100T
OTHERS PARTS GROUP
BK501 nsp
BRACKET,PCB CMD1A569
BN501 nsp WIRE ASS'Y CWB1B013150HC *
BN502 nsp
WIRE ASS'Y CWB1B007150HC *
BN505 nsp
WIRE ASS'Y CWB4B003250HC *
BN508 nsp
PINHEADER(11P,1.25mm,STRAIGHT,B-TO-B) CJP11GI281Z
CN503 nsp WAFER(3.96MM) CJP03GA148ZW
CN510 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY
CN520 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY
CN530 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY
CN540 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY
CN550 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY
ET501 nsp PALTE,EARTH HJT1A025
JK501 943646010250S JACK,SPK(4PRR/BB,SCREW) CJJ5P011U
JK502 943646010240S JACK,SPK(6PRRR/BBB,SCREW CJJ5R008U
L5101 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD *
L5201 943115100310S
COIL,SPEAKER(0.5UH) CLEY0R5KAD *
L5301 943115100310S
COIL,SPEAKER(0.5UH) CLEY0R5KAD *
L5401 943115100310S
COIL,SPEAKER(0.5UH) CLEY0R5KAD *
L5501 943115100310S
COIL,SPEAKER(0.5UH) CLEY0R5KAD *
RY560 943682000810S
RELAY,BC3-12H,DC12V,2C2P CSL4A016ZU
RY562 943682100270S RELAY,981-2A-12DS,DC12V,2C1P CSL3A022ZU *
RY563 943682100270S
RELAY,981-2A-12DS,DC12V,2C1P CSL3A022ZU *
RY564 943682100270S
RELAY,981-2A-12DS,DC12V,2C1P CSL3A022ZU *
TU500 943183100200S
TUNER,FM(SCREW:FTYPE),SI4704-B20 1713E3
CNVMW004FV1-
S63SV
*
TU500 943183100210S
TUNER,RDS,FM(PALTYPE),SI4705-B20 1713E2
CNVMW104FV1-
S63V
*
TU500 943183100220S
TUNER,NORDS,FM(PALTYPE),SI4704-B20
171KE1C,
1723E1C
CNVMW004FV1-S63 *

Denon AVR-1613 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby TrueHD, DTS Neo:6, DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	150.8 mm
Width	434.3 mm
Height	328.9 mm
Weight	8300 g
