Denon AVR-1613 Service Manual

166
Ref. No. Part No. Part Name Remarks Q'ty New
R7254 nsp
RES,CHIP(1608/5%/51ohm) CRJ10DJ510T
R7255 nsp RES,CHIP(1608/5%/51ohm) CRJ10DJ510T
R7261 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R7262 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R7263 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R7264 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R7265 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R7266 nsp RES,CHIP(1608/5%/5.1ohm) CRJ10DJ5R1T
R7267 nsp RES,CHIP(1005/5%/1.8Kohm) CRJ06IJ182T
R7268 nsp RES,CHIP(1005/5%/1.8Kohm) CRJ06IJ182T
R7269 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7270 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R7271 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R7272 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R7273 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R7274 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7276 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7278 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7280 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R7281 nsp RES,CHIP(1005/5%/5.6Kohm) CRJ06IJ562T
R7282 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7283 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7284 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7286 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R7288 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7289 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7290 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7291 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7292 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7293 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7294 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7295 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7296 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7297 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7298 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7299 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7300 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7301 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7501 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7502 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7505 nsp RES,CHIP(1608/1%/47Kohm) CRJ10DF4702T
R7506 nsp RES,CHIP(1608/5%/680Kohm) CRJ10DJ684T
R7507 00MNN05154610 RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T
R7508 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7512 90M-NN000680R RES,CHIP(1608/1%/300Kohm) CRJ10DF3003T
R7513 nsp RES,CHIP(1608/5%/1.5Mohm) CRJ10DJ155T
R7514 00MNN05154610 RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T
R7515 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7516 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7519 nsp RES,CHIP(1608/1%/470Kohm) CRJ10DF4703T
R7520 00MNN05105610 RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T
R7521 00MNN05154610 RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T
R7526 nsp RES,CHIP(1608/1%/120Kohm) CRJ10DF1203T
R7527 00MNN05105610 RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T
R7528 00MNN05154610 RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T
R7529 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7530 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7531 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7532 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7533 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7534 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7535 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7536 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7537 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7538 nsp RES,CHIP(1005/5%/3.3Kohm) CRJ06IJ332T
R7539 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7540 nsp RES,CHIP(1005/5%/3.3Kohm) CRJ06IJ332T

Denon AVR-1613 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby TrueHD, DTS Neo:6, DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	150.8 mm
Width	434.3 mm
Height	328.9 mm
Weight	8300 g
