Denon AVR-1613 Service Manual

52
Error
Code
Details of Error code Display Coping strategies
21
No FirmwareFile in USB after
SBLMode.
F i l e s N o t F o u n d 2 1
Disconnect and connect the USB
memory.
22
FirmwareFile in USB after SBLMode
for unsupported Model name/area
N o t M a t c h F i r m 2 2
Check the supported Model name/area
for the FirmwareFile.
23
Failed to obtain entire Firmware
information after SBLMode.
C o n n e c t i o n F a i l 2 3
Disconnect and connect the USB
memory.
24
TimeOut while obtaining entire
Firmware information after SBLMode
C o n n e c t i o n F a i l 2 4
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error
display, press and hold the
X
button for
ve seconds.
25 Failed to transit to SBLMode.
C o n n e c t i o n F a i l 2 5
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error
display, press and hold the
X
button for
ve seconds.
26
TimeOut in Download (writing to
SDRAM) for FirmwareDownload
D o w n l o a d f a i l 2 6
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error
display, press and hold the
X
button for
ve seconds.
27
Failed to write to EEPROM after
SBLMode.
C o n n e c t i o n F a i l 2 7
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error
display, press and hold the
X
button for
ve seconds.
36 Unable to detect USB.
C o n n e c t i o n F a i l 3 6
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error
display, press and hold the
X
button for
ve seconds.
37 No FirmwareFile in USB.
F i l e s N o t F o u n d 3 7
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error
display, press and hold the
X
button for
ve seconds.
38
FirmwareFile in USB for unsupported
Model name/area
N o t M a t c h F i r m 3 8
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error
display, press and hold the
X
button for
ve seconds.
39 TimeOut in USBCheck
C o n n e c t i o n F a i l 3 9
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error
display, press and hold the
X
button for
ve seconds.
3A
Unable to detect USB for
FirmwareDownload.
C o n n e c t i o n F a i l 3 A
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error
display, press and hold the
X
button for
ve seconds.
3B
No FirmwareFile for
FirmwareDownload.
F i l e s N o t F o u n d 3 B
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error
display, press and hold the
X
button for
ve seconds.
3F Failed to transit to SBLMode.
C o n n e c t i o n F a i l 3 F
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error
display, press and hold the
X
button for
ve seconds.
50 Unable to detect USB.
C o n n e c t i o n F a i l 5 0
This unit automatically retries several
times. Wait until the FL display stops.
If the FL display stops at the Error
display, press and hold the
X
button for
ve seconds.

Denon AVR-1613 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby TrueHD, DTS Neo:6, DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	150.8 mm
Width	434.3 mm
Height	328.9 mm
Weight	8300 g
