Denon AVR-1613 Service Manual

56
3.4. Devicedisplayduringrmwareupdate
Display of target device during rmware update.
Target device Display Error code when an error occurs
Main CPU
M a i n : * * % * * * m i n
08 - 0B
10 - 15
20 - 27
36 - 3B
3F
Audio PLD
A P L D : * * % * * * m i n
50 - 52
54 - 58
5A - 64
DSP
D S P : * * % * * * m i n
50 - 52
54 - 58
5A - 64
GUI Serial Flash
G U I : * * % * * * m i n
50 - 52
54 - 58
5A
62 - 64
80 - 86
DM860A Boot Loader
E S B L : * * % * * * m i n
A0 - A4
A6 - A7
AE - B5
DM860A Image
E I M G : * * % * * * m i n
A0 - A4
A6 - A7
AE - B5
DM860A Image
(
EmergencyMode)
U p d a t e r e t r y
–
Conrmingthermware’snumberafterupgraded
After updating the rmware, check the version. Refer to "
1.μcom/DSPVersiondisplaymode
" (18 page).

Denon AVR-1613 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby TrueHD, DTS Neo:6, DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	150.8 mm
Width	434.3 mm
Height	328.9 mm
Weight	8300 g
