Denon AVR-1613 Service Manual

73
Checking the USB device
YES
Is the USB device compatible with the set?
Are you using a USB hub?
Only mass storage devices in FAT16 or
FAT32 formats or MTPcompatible devices
and iPod (Remove some models) are
supported.
Don't use the USB hub.
NO
YES
NO
Checking the set (AV RECEIVER)
YES
YES
Is a voltage (5V) being supplied between pins 1 and 4 of JK101 on
the USB board (USB connector)?
The circuitry from IC853 on the DIGITAL board to JK101 on the USB
board is defective.
Is the wire properly connected between CN851 on the DIGITAL board
and BN104 on the USB board.
The IC854 and surrounding circuitry on the
DIGITAL board is defective.
Connect the wire properly.
NO
NO
5.2. USBdeviceisnotrecognized

Denon AVR-1613 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
FM band range	87.5 - 107.9 MHz
Supported radio bands	FM
Internet radio services supported	Pandora, SIRIUS Internet Radio
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby TrueHD, DTS Neo:6, DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	150.8 mm
Width	434.3 mm
Height	328.9 mm
Weight	8300 g
