Denon AVR-1613 Service Manual

85
BN501
13.DGND 12.MUTE_+B 11.RLY_GND 10.+12V 9.FR 8.AGND 7.SR 6.AGND 4.AGND 5.CEN 3.SL 2.AGND 1.FL
BN502
1.FRONT_RLY 2.C/S_RLY 3.H/P_RLY 4.ASO_DET 5.DC_PROT 6.THERMALDET_A 7.THERMALDET_B
CEN
FR SR SL FL
Q5703
Q5108Q5208Q5308Q5408Q5508
Q5705Q5708
Q5706
Q5704
Q5407 Q5107Q5207Q5307Q5507
Q5707
R5126R5226R5326R5426R5526
Q5701
C5620 C5619
C5618
C5617
C5616
Q5601 Q5603 Q5604 Q5602
MAIN
(FOIL SIDE)
181716151413121110987654321
M
L
K
J
I
H
G
F
E
D
C
B
A
鉛フリー半田
半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。
Lead-free Solder
When soldering, use the Lead-free Solder (Sn-Ag-Cu).
